|Hose length (max):||max. 37m (od 20mm)|
|Hose:||not included but available on request|
|Nominal width:||12mm (1/2")|
|Inlet (swivel):||1/2" inner thread|
|Outlet (pipe bend):||1/2" inner thread|
|Operating pressure:||max. 200bar (at extra charge up to 300bar)*
|Temperature:||1-100°C (at extra charge up to 180°C)**
|Dimensions:||see downloads on the left|
|Suitable substances:||water / cleaning supplies / air / oil / grease / etc.**|
|Angled swivel:||WDTH12/Aluminium B1070003504 (AISI304 at extra charge)*|
Hose guide window
* A stainless steel angled swivel with a nominal width of 1/2" (12 mm) can be used for the application of hose reels up to 300bar. The additional cost item number is MP10700035011.
** When using chemicals or high temperatures are needed, sealings of Viton must be installed. The item number for additional costs of 3/8" and 1/2" hose reels is M1071001201. For EPDM you have to order the following item number M1071001202.
